VEC UHD - High performance FPGA-based 4K/UHD 10bit 4:2:2 HEVC video encoder with 12G SDI and HDMI 2.0 Inputs

Input:

​

HDMI   UHD

SDI          3G-SDI 1080p60 , 12G SDI UHD

CVBS      NTSC/PAL

Encoding:

​Codec: ​ H.265, H.264 Base/Main/High

Protocols:       RTSP/ RTMP(S)/ HTTP/ TS/ HTTP/

                         FLV/ HLS/SRT/ UDP multicast/ RTP multicast

                        Facebook, WOWZA, Youtube Live

Bitrate:             32-32000 Kbit/s (CBR/VBR)

Framerates:     5-60FPS

Features:​

  • Xilinx FPGA architecture

  • Simultaneous SDI and HDMI encoding

  • 10bit 422 4K/UHD

  • 10bit 444 1080p

  • Embedded or 2X external audio

  • TS recording onto USB 3, Micro SD

  • Industrial temperature range

UHD 4K video encoder
Broadcast video encoder

Audio: ​

​

AAC   48000~320000

AAC+  24000~48000

AAC++  12000~32000

MP3  64000~320000

MP2  64000~320000

AC3  40000~640000

Opus  40000~640000

Physical:

​

Dimensions: 110x105mm

Power: 11-15VDC

Consumption: 12W Max

Onboard connectivity: Serial port, USB, GPIO Headers

Resolutions:

​

4096x2160/3840x2160/2560x1440/

1980x1200/1920x1080/1680x1056/

1600x1200/1600x900/1280x1024/1280x720

---240x180/ Auto follow input
